Unit net weight 0.0166 Kg/m
Inner diameter (iØ) 4 mm
Outer diameter (oØ) 6 mm
Print *MB* RILSAN® PA11 DIN 73378 Ø 6X4 PA11 PHL Made in Italy
Minimum bending radius 30 mm
Norms DIN 73378
Operating pressure (23°C - SF 3:1) 26 BAR Wall hickness 1 mm
Operating pressure (23°C - SF 4:1) 20 BAR
Flexibility 345 MPa
Hardness 60 Sh D
Yield strength 26 MPa
Breaking load 48 MPa
Breaking deformation >200 %
Elongation at yield 52 %
Charpy notched impact strength (23°C) N.B. J/m2
Charpy impact strength (23°C) N.B. kJ/m2
Charpy notched impact strength (-40°C) 7 kJ/m2
Charpy impact strength (-40°C) N.B. kJ/m2
Melting point 181 °C
Density 1,04 g/cm3
