Unit net weight 0.0081 Kg/m
Inner diameter (iØ) 2.5 mm
Outer diameter (oØ) 4 mm
Print *MB* RILSAN® PA11 DIN 73378 Ø 4X2,5 PA11 PHL Made in Italy
Minimum bending radius 15 mm
Norms DIN 73378
Operating pressure (23°C - SF 3:1) 30 BAR
Wall thickness 0.75 mm
Operating pressure (23°C - SF 4:1) 23 BAR
Flexibility 345 MPa
Hardness 60 Sh D
Yield strength 26 MPa
Breaking load 48 MPa
Breaking deformation >200 %
Elongation at yield 52 %
Charpy notched impact trength (23°C)
N.B. kJ/m2
Charpy impact strength (23°C)
N.B. kJ/m2
Charpy notched impact strength (-40°C)
7 kJ/m2
Charpy impact strength (-40°C) N.B. kJ/m2
Melting point 181 °C
Density 1,04 g
