Medium Pressure Push-in Fittings, 80 bar
| MT21 06 M10x1 | Brass | M10x1 | -50/+100 °C | 0/16 bar | --- | 14,5 | 16,2 | 14 | 9 | 36,7 | 6,3 | 19,5 | 50 | 4 | 6 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 08 M10x1 | Brass | M10x1 | -50/+100 °C | 0/16 bar | --- | 16,5 | 16,2 | 14 | 11 | 45,3 | 6,3 | 20,5 | 52 | 6 | 8 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 06 M12x1,5 | Brass | M12x1,5 | -50/+100 °C | 0/16 bar | --- | 14,5 | 17,3 | 15 | 9 | 43,1 | 8,3 | 23,8 | 50 | 4 | 6 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 06 M14x1,5 | Brass | M14x1,5 | -50/+100 °C | 0/16 bar | --- | 14,5 | 19,6 | 17 | 9 | 45,8 | 8,3 | 23,5 | 50 | 4 | 6 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 06 M16x1,5 | Brass | M16x1,5 | -50/+100 °C | 0/16 bar | --- | 14,5 | 22 | 19 | 11 | 56,4 | 8,3 | 24 | 52 | 4 | 6 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 08 M12x1,5 | Brass | M12x1,5 | -50/+100 °C | 0/16 bar | --- | 16,5 | 17,3 | 15 | 11 | 50,3 | 8,3 | 24,5 | 52 | 6 | 8 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 08 M14x1,5 | Brass | M14x1,5 | -50/+100 °C | 0/16 bar | --- | 16,5 | 19,6 | 17 | 11 | 53,8 | 8,3 | 25 | 52 | 6 | 8 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 08 M16x1,5 | Brass | M16x1,5 | -50/+100 °C | 0/16 bar | --- | 16,5 | 22 | 19 | 11 | 57,2 | 8,3 | 24,5 | 52 | 6 | 8 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 08 M22x1,5 | Brass | M22x1,5 | -50/+100 °C | 0/16 bar | --- | 18,5 | 31,2 | 27 | 15 | --- | 8,1 | 26,5 | 52 | 6 | 8 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 10 M12x1,5 | Brass | M12x1,5 | -50/+100 °C | 0/16 bar | --- | 18,5 | 17,3 | 15 | 13 | --- | 8,3 | 25,5 | 58,6 | 8 | 10 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 10 M14x1,5 | Brass | M14x1,5 | -50/+100 °C | 0/16 bar | --- | 18,5 | 19,6 | 17 | 13 | --- | 8,3 | 26 | 58,6 | 8 | 10 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 10 M16x1,5 | Brass | M16x1,5 | -50/+100 °C | 0/16 bar | --- | 18,5 | 22 | 19 | 13 | 27,8 | 8,3 | 26 | 58,6 | 8 | 10 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 10 M22x1,5 | Brass | M22x1,5 | -50/+100 °C | 0/16 bar | --- | 18,5 | 31,2 | 27 | 15 | --- | 8,1 | 26,5 | 60,6 | 8 | 10 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 12 M12x1,5 | Brass | M12x1,5 | -50/+100 °C | 0/16 bar | --- | 21 | 17,3 | 15 | 15 | 82,3 | 8,3 | 26,7 | 62 | 9 | 12 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 12 M14x1,5 | Brass | M14x1,5 | -50/+100 °C | 0/16 bar | --- | 21 | 19,6 | 17 | 15 | 83,5 | 8,3 | 26,8 | 62 | 9 | 12 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 12 M16x1,5 | Brass | M16x1,5 | -50/+100 °C | 0/16 bar | --- | 21 | 22 | 19 | 15 | 87 | 8,3 | 27,3 | 62 | 9 | 12 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 12 M22x1,5 | Brass | M22x1,5 | -50/+100 °C | 0/16 bar | --- | 21 | 31,2 | 27 | 15 | --- | 8,1 | 27,6 | 62 | 9 | 12 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 15 M16x1,5 | Brass | M16x1,5 | -50/+100 °C | 0/16 bar | --- | 27 | 22 | 19 | 19 | --- | 8,3 | 30,2 | 74 | 12 | 15 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 15 M22x1,5 | Brass | M22x1,5 | -50/+100 °C | 0/16 bar | --- | 27 | 31,2 | 27 | 19 | --- | 8,1 | 30,5 | 74 | 12 | 15 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 16 M16x1,5 | Brass | M16x1,5 | -50/+100 °C | 0/16 bar | --- | 27 | 22 | 19 | 19 | --- | 8,3 | 30,2 | 75 | 12 | 16 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 16 M22x1,5 | Brass | M22x1,5 | -50/+100 °C | 0/16 bar | --- | 27 | 31,2 | 27 | 19 | --- | 8,1 | 30,5 | 75 | 12 | 16 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
| MT21 18 M22x1,5 | Brass | M22x1,5 | -50/+100 °C | 0/16 bar | --- | 29 | 31,2 | 27 | 21 | --- | 8,1 | 32,5 | 78 | 14 | 18 | NULL | 0/232 psi | -58/212 °F | TUV | SILICONE FREE | RoHS | REACH |
