NON-RETURN - RHD - M52X2 - 100
1246844
NON-RETURN VALVES RHD
Male thread 1,0 BAR
Application: Non-return valves enable a flow in one direction and block it in the opposite direction.
F1: M52X2
WP (bar): 100
Opening pressure (bar): 1
CH (mm): 65
CH1 (mm): 75
L (mm): 99,5
Q1 (mm): 77,5
Flow: 2-1
Temp. : -40 - 120
:
