POWERFLEXBIO 6000 - HI-TUFF - 4WS - 1/2" - 420
1001735
ISO 18752 - exceeds SAE 100 R15
Tube: oil resistant synthetic rubber and biodegradable hydraulic fluids.
Reinforcement: four/six high tensile steel spirals.
Cover: smooth up to 1", wrapped over 1". Abrasion, ozone and hydrocarbon resistant synthetic rubber.
Application: developed to withstand very demanding
conditions, very high performance in pressure, pulsing and
flexing.
Temperature: -40 °C +121 °C (-40 °F +250 °F)
Length: random up to 1" - 61 m max over 1"1/4
DH SCAN crimp short code: up to 1": PFB60 / 1 1/4" 4WS:
PFB60-4S / 6WS: PFB60-6S
ID (Dash): 8
ID (in): 1/2"
ID (mm): 13
OD (mm): 23
WP (Bar): 420
WP (psi): 6000
BP (Bar): 1680
BP (psi): 24000
BR (mm): 90
Weight (kg/m): 0,745
DH SCAN crimp short code: (http://crimp.dunlophiflex.se/Home/Index/DK): PFB6K
